Legacy Embedded Flash Solutions

Drive On Module - USB

Innovative USB Drive on Module

MEMKOR USB Drive on Module, using UDRW Technology, offers unique feature enabling drive partitioning into CD-ROM, Removable Disk and Hidden Memory zones.

The CD-ROM partition is read-only and prevents accidental or malicious data alteration. The Removable Disk partition functions as a regular USB flash storage.

The Hidden Memory Zone is not visible to the OS. It defines a safe zone where confidential corporate and/or personal data can be securely stored.

In addition, the Secure Erase feature enables fast data erasure from any drive partition (approx 10s/1GB).

Our USB Drive on Module is built using a unique chip that integrates high density Flash memory and Flash controller in one package, ensuring the smallest device footprint.

Interface

Universal Serial Bus (USB) v2.0

Connector

2.54mm pitch 10pin female connector

High Speed Interfaces

Ultra DMA Mode-4
Multiword DMA Mode-2
PIO Mode-4

Capacity

1GB, 2GB

Industrial Operating Temperature Range

0ºC to +70ºC

Operating Voltage

5V±10%

High Data Security

The hidden zone can be used as secure partition to store data enabling either data or application protection
Password controlled access to removable disk partition and Disk Lock upon 5 unsuccessful login attempts
Secure Erase triggered by a command or combined with Disk Lock feature
Hardware write protection

Drive On Module - PATA

MEMKOR PATA Drive On Module (DOM) for embedded systems offer high reliability, capacity and performance. They operate where extreme temperatures, vibration and humidity are the norm.

With implemented S.M.A.R.T., write protect and password controlled drive access, Memkor Drive On Module raise the bar for embedded Flash product feature set.

Our PATA Drive on Module supports 40-Pin and 44-Pin connectors, straight and angle configurations.

High performance of up to 25MBps sustained read rate improve boot time and system response time.

Memkor offers customer controlled Bill Of Material (BOM) to facilitate smooth qualification and make product ownership easy.

Connector

40/44 pins connectors
Straight/angle/reverse angle

High Speed Interfaces

Parallel ATA

Fast boot time and application response

25 MB/s max sustained read rate
11 MB/s max sustained write rate

High speed interfaces

Ultra DMA Mode-4
Multiword DMA Mode-2
PIO Mode-4

Operating Voltage

5V±10%

High Data Reliability

Data stored on SLC NAND managed by dynamic wear leveling and ECC/EDC
27+ years write endurance when overwriting entire disk 10 times per day
10 years data retention

Unmatched Data Integrity

Up to 8 user defined read-only partitions to prevent accidental or malicious data alteration

Unmatched Data Security

Password control feature prevents unauthorized access

Flash Health monitoring and reporting

S.M.A.R.T. to monitor flash usage
